70990-XX Turbodisk Assembly - Parts List
70990-XX Turbodisk Assembly - Parts List
Literature:
| Part # | Description | Qty |
| 70976-01 | Feed Tube Kit, Downfeed | 1 |
| 8156-24F | Screw, 5/16-24 x 3/4", Hex Head | 2 |
| 8156-32F | Screw, 5/16-24 x 1", Hex Head | 5 |
| 8156-40F | Screw, 5/16-24 x 1-1/4", Hex Head | 1 |
| 7734-07 | L Washer, Spring, 5/16" | 6 |
| 17274-00 | High Voltage Connector Assembly | 1 |
| 15980-00 | Extension Arm, Air Motor | 1 |
| 1613-03 | Tube Support, 20-3/8" | 1 |
| 8156-48F | Screw, 5/16-24 x 1-1/2", Hex Head | 2 |
| 27141-081 | Hose Wrapping | 25' |
| 15946-00 | Groudning Hook Assembly | 1 |
| 10384-01 | Tubing, Latex, 3/16" ID x 1/16" Wall | 50' |
| 9704-03 | Tubing, LD/PE, 1/4" OD x 0.17" ID | 100' |
| 7113-13 | Tubing, 1/2" OD x 0.06" Wall, Nylon | 50' |
| SSP-5020 | Tubing, 3/8" OD x 1/4" ID | 100' |
| 55994-26 | Tubing, 1/2" OD x 3/8" ID | 100' |
| 41-FTC-1002 | Fitting, Connector, 3/8" T x 1/4" NPT | 4 |
| LSFI0005-01 | Connector, Striaght, 1/2" OD Tube x 1/4" NPT | 4 |
| 78006-00 | Elbow, 3/8" OD Tube x 1/4" NPT | 2 |
| LSFI0004-01 | Street Tee, 1/4" NPT, SS | 1 |
| 70590-01 | Connector, Male, 1/4" OD Tube x 1/4" NPT, SS | 1 |
| LSFI0006-01 | Elbow, 1/4" OD Tube x 1/4" NPT Female, SS | 1 |
| LSFI0038-00 | Elbow, SST, 1/4" NPT(F) x 1/8" NPT(M) | 1 |
| SSV-809 | Check Valve, 1/4" NPT, Male | 1 |
| 76462-00 | Fitting, SST, 1/4" NPT, Male, Branch Tee | 1 |
| LSFI0018-01 | Ferrule Kit, 1/2" Nylon | 1 |
| 55994-23 | Tubing, FEP, 0.156" ID x 0.25" OD | 5' |
| LRPM0105 | Bracket | 1 |
| CCV-12-SS | Valve Adapter | 1 |
| 18283-02 | Valve Assembly, 3-Way | 1 |
| CCV-403-SS | Trigger Valve Assembly | 1 |
| LSFI0009-01 | Elbow, Street, 1/4" NPT, SS | 1 |
| SSP-6054 | Connector, 1/4" OD Tube x 1/8" NPT, Male Brass | 1 |
| SSP-39 | Reducer, 1/8" NPT, Male x 1/4" NPT, Female, SS | 2 |
| 55994-23 | Tubing, FEP, 0.250" OD x 0.156" ID | 5' |
| 55994-24 | Tubing, FEP, 0.250" OD x 0.126" ID | 5' |
| 55994-28 | Tubing, FEP, 0.188" ID x 0.250" OD | 5' |
| SSP-6427 | Elbow, 1/4" OD Tube x 1/8" NPT, Brass | 1 |
| SSP-1421 | Plug, Hex Socket, 1/4" NPT | 1 |
| 70590-01 | Connector, Male, 1/4" OD Tube x 1/4" NPT, SS | 2 |
| 7958-56C | Screw, 1/4-20 x 1-3/4" Lg., Hex Head | 2 |
| 8156-48F | Screw, 5/16-32 x 1-1/4" Lg., Hex Head | 2 |
| 7734-06 | L Washer, 1/4" | 4 |
| 7734-07 | L Washer, 5/16" | 2 |
| 78004-00 | Bushing, 1/2" NPT Male x 1/4" NPT Female, SS | 2 |
| 17366-00 | Repair Kit, 3-Way Valve | 1 |
| 78006-00 | Elbow, Street, 1/4" NPT, SS | 2 |
| SSP-6439 | Elbow, Swivel, Male, 1/4" OD x 1/4" NPT, Brass | 1 |
| LSFI0007-01 | Elbow, 1/4" OD Tube x 1/4" NPT Male, SS | 2 |
| 70171-04 | Flow Regulator Assembly | 1 |
| 74151-XX | Flow Regulator, DR-1 | 1 |
| 70589-05 | Fitting, 1/4" OD Tube, Special | 1 |
| 8212-32F | Screw, Regulator Mounting | 2 |
| 7787-02 | Adapter, 1/4" NPSF to 1/4" NPTF, Carbon Steel | 1 |
| LSFI0004-01 | Tee, Street, 1/4" NPT | 1 |
| SSF-8125 | Hex Jam Nut | 1 |
| 20810-00 | Bracket, Regulator | 1 |
| LSMM0025-00 | Bracket, Regulator | 1 |
| KK-4841 | Repair Kit, CCV-403-SS | 1 |
| CCV-7 | Valve Tool | 1 |
