Sagola 5050X Air Pre-Filter

5050X Air Pre-Filter - Stage 1

Manufacturer: Sagola

Part #: PT10720301

Description: Air from a compressor circulating through the network contains particles and solid impurities, water from the relative humidity of the suction air and burnt oil from the compressor. All these impurities accompanied by compressed air reach the vital parts of tools causing oxidation and premature wear.

For these reasons it is necessary to eliminate impurities by means of a filter, taking into account that the maximum performance with the minimum pressure loss must be obtained. SAGOLA FILTRATION SYSTEMS guarantee the maximum air quality and the minimum pressure loss throughout the line.

Stage 1 Air Filtration Systems

Centrifugal force for large particulates, water & oil

1. The friction of the compressed air against the walls of the unit produces a decanting of solid and liquid particles which fall to the bottom of the unit’s vessel.

2. The compressed air is forced through the porous brass filter, in a downward flow, generating an increase in speed which then sharply changes to an upward direction that produces a further decanting of the liquid particles that were in condensation

• The Sagola 5050X is an air regulator filter, ideal for pre-filtration in industrial airlines.

• Designed for the outlet of medium compressors (inlet 1/2”) and ideal
  for changes in height levels in the line network, booths inlets, etc.

• Semi-automatic draining system.

• Tough machined aluminum casing.

• Friction and centrifugal filtration with an 8-micron porous brass filter to retain water, oil, and other impurities.

• 3 Year warranty & minimal maintenance.

• Tough heavy-duty construction for long service life.

Literature:

• Manual
• Data Sheet
• Information Sheet
• Brochure

Specifications:
