Rotary Screw Single Stage Gasoline - AR1-PK37-M
Rotary Screw Single Stage Gasoline - AR1-PK37-M
AR1-PK37-M
Powered by industry proven components, the patented Mi-T-M Rotary Screw Compressor works great in a wide variety of applications. This compact machine produces 115 CFM @ 100 PSI, and the 10-1/2-gallon fuel tank gives you the extended run time needed on many jobsites.
Compressor Pump: Integrated air/oil separator · Integrated thermostatic bypass valve · Integrated oil filter · Banded 4 V-belt drive system · Easy-to-read oil level indicator · High oil temperature shutdown
Engine: Electric start - battery and cables included · Low-oil level shutdown
Frame: Powder coated steel frame with 1-1/4-inch roll cage, handle, 4-point lifting hook, winch point and tie-down anchors · 15-inch pneumatic tires
Components: 10-1/2-gallon aluminized steel fuel tank · Oil cooler with guard · Pressure gauge · Ball valve controlled 3/4-inch outlet · Adjustable pilot valve adjusts engine RPM based on air power needed
Specifications
-
CFM @ 100 PSI
115
-
Displacement/ Engine
999cc Kohler CH1000 OHV
-
Compressor
Single Stage, Rotary Screw
-
Engine Idle Control
Pneumatic
Weights & Dimensions
-
Net Weight
698.00 lbs.
-
Shipping Weight
770.00 lbs.
-
Length
50.75 in.
-
Width
30.50 in.
-
Height
43.50 in.
Options
-
AX-0076 Skid Feet
Stationary applications
Limited Warranties:
- 3 Year Kohler Engine
- 3 Year Standard when RotorLub™ Oil, Filters and Parts are used at the prescribed intervals
